Tolerance Analysis Simplified
Excel-based tolerance analysis that makes it easy to be thorough.
About Powerstaxx™
is the tool to use when you have many stack-ups to do, especially when one dimension is used in multiple stack-ups.
has associative dimension management. Change the dimension value in one place and it changes wherever it is used.
makes it easy to be thorough when doing a tolerance analysis.
helps manage risk in your project
is Excel® based and easy to use.
is cost effective.
Features
Up to 200 tolerance stack ups, with associative dimensions.
Multiple stack ups per page for easy review.
Worst case, RSS, and modified RSS stack-ups.
Linear and non-linear stack-ups
Easily choose between analyzing nominal values, first article values, validation values, or any combination.
A "times used" feature to provide an alert if a dimension is used more than once.
Graphical output of stack-up results.
A location for an image of the stack-up dimensions.
Choose whether to use worst case or RSS to highlight out of spec conditions.
An automatically generated summary sheet of all stack-ups.
Predict rejects per user defined lot size.
Easy Setup
Get started quickly with a user-friendly Excel template designed for engineers.
Accurate Results
Perform detailed tolerance analysis that you can trust for your engineering projects.
Save time and reduce errors with automated calculations tailored to your needs.
